Counterweights Not Required
Only 3.4kg weight
±2.5arcsec PE
Capacity 13.5kg (max 18kg)
Strain Wave Gear (Harmonic Drive)
Renishaw encoder
5-years warranty
Although the capacity is 13.5kg (maximum 18kg), the weight of the mount is only 3.4kg. It fits in one hand, so you don’t need a separate large bag for this. The lighter the mount, the greater the frequency of use.
A high-resolution encoder from Renishaw is built into the RA axis. As a result, a periodic error of only ±2.5 seconds was achieved. Choose the RST-135E mount if you are bothered or reluctant to use the autoguide system.
Counterweights not required up to 13.5kg. It is especially convenient for domestic mobile observation as well as overseas expedition observation.
The performance of the worm gear mount is sensitive to the balance, but the RST-135E is not. No need to rebalance even if you change the eyepiece or camera.
Instead of worm gears, a new type of reducer called strain wave gear (harmonic drive) is used. Almost no backlash and no maintenance is required. As it is widely used in industrial robots, it is very durable.
CNC machined aluminum alloy AL6061 is used for aircraft. That’s why it’s small, light and stiff. The beauty of the machined surface increases the collection value.
WiFi is built in. You can control the mount via the SkySafari app on your smartphone. Ascom Driver can be connected via WiFi as well as USB. GOTO and AutoGuide are now wireless.
GPS receiver is built in. The position and time of the observer can be entered accurately and conveniently.
There is a built-in home sensor to find the mechanical origin. This is useful for permanently using Star Alignment data. Build an ultra-small remote observatory with the RST-135E mount.
| Specification | |
|---|---|
| Mount type | Dual mount – German Equatorial, Alt-Azimuth |
| Reducer | Strain wave gear (Harmonic Drive) |
| Load Capacity | 13.5kg(without counter weight), 18kg(with counter weight) |
| Recommend Telescope | 8inch Reflector, 5inch Refractor |
| Weight | 3.4kg |
| Volume | 14.4 x 13.1 x 20.5 cm |
| Material | Aluminum alloy AL6061, Steel, Brass |
| Surface coating | Anodizing |
| Reducer size(RA) | Model No. 17 (Based on HDS) |
| Reducer size(DEC) | Model No. 14 (Based on HDS) |
| Motor | Swiss made Maxon DC Servo Motor |
| Latitude range | 0 to 90 degrees |
| High resolution encoder | Built-in RA axis, Renishaw |
| Specification | |
|---|---|
| Max Slew Rate | 1,800x (7.5deg/sec) – 16V DC |
| Input Power | DC 12V ~ 16V |
| Power Consumption(Tracking, 12V) | 0.2A |
| Power Consumption (Slew, 12V) | 1.0~2.0A |
| PC Connection | ASCOM Driver |
| GPS | Built-in (Hand Controller) |
| WiFi | Built-in (Hand Controller) |
| Home Sensor | Built-in |
| Compatibility | ASIAIR, StellarMate |
| Periodic error | ±2.5arcsec (430sec) |
INCLUDED ITEMS:
RST-135E mount
Hand controller (Hubo-i SE)
Cable for hand controller
USB cable
Power cable (5.5×2.1mm DC)
Adapter for camera tripod(3/8″ thread)
Adapter for PoleMaster
Soft case for mount
4mm Hex Wrench
